No

Kod

Parça Adı

1

83-140410-ABW

ASSEMBLY COMPLETE REAR PARCEL SHELF TRIMMED

1

83140414AAW

Trim panel, rear parcel shelf border

1

83140413AAW

Infill panel, rear parcel shelf

1

697571

NUT LOKUT

9

697468

SCREW/WASHER No8 x19 PAN HD AB

1

697565

Spire Nut

2

83140166ABW

Panel, rear quarter, complete, RH

2

83140168ABW

Panel, rear quarter, trimmed, RH

2

93140392

Trim panel assy, rear bulkhead

2

83-83736

ESCUTCHEON

2

80-123498-AA

GRILLE-REAR PARCEL SHELF

3

83140167ABW

Panel, rear quarter, complete, LH

3

83140169ABW

Panel, rear quarter, trimmed, LH

4

83140396ACW

Rear luggage decklid assy, trimmed

4

85-82712

PAD ROOF PANEL FRONT AND REAR

10

697470

NUT M5 NYLOC

10

697679

NUT

6

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

5

83140540AAW

Luggage strap assy, upper

6

697114

SCREW M6 x 20 HEX FLANGE HEAD GRD 8.8

6

697516-PK

NUT-M6 HEX BLK (10)

6

83140535AAW

Luggage strap assy, lower

6

78-82424

WASHER SPACING 2 mm

7

83150046AAW

Rear quarter panel assy, complete, RH

7

83150062ABW

Spine panel, complete, trimmed

8

83150047AAW

Rear quarter panel assy, complete, LH

8

83-150044-AAW

Panel rear quarter trimmed, RH

8

83150045AAW

Panel rear quarter trimmed, LH

9

83150058ABW

Trim, buttress, RH

9

83150059ABW

Trim, buttress, LH

9

697616

SCREW FLG HEAD ST

10

83-150054-AAW

BLANKET ASSY TRIMMED - REAR BULKHEAD

10

83-150028-AB

ASSEMBLY BULKHEAD PANEL RH

10

83-150029-AB

ASSEMBLY BULKHEAD PANEL LH

10

83-150040-AB

ASSEMBLY LUGGAGE DECK RH

10

83-150041-AB

ASSEMBLY LUGGAGE DECK LH

10

697514

WASHER OVAL 1 x 1/2 x 7/32

10

83-84823

SNAPSAC

10

80-90178

FIXING - FIR TREE

10

83-111423-AA

VELCRO HOOKS (100mm x 25mm)

10

83-111424-AA

VELCRO LOOPS (100mm x 25mm)

10

697624

SCREW No8 x 25 RSD CSK HEAD BLACK
