Aston Martin Yedek Parça - DBS V12 - Engine Sealing
Parça Kodları
No
Kod
Parça Adı
1
8G43-6A505-AA
COVER ASSY - VALVE ROCKER ARM COVER LH
1
8G43-6582-AA
COVER ASSY - VALVE ROCKER ARM RH
2
07-85057
Gasket, Valve Cover, LH
2
07-85056
Gasket, Valve Cover, RH
3
07-85055
BAFFLE-PCV
4
703175
SCREW M4 x 10 PAN TORX CHROME FREE
5
7G43-6P068-AA
COIL COVER SPARK PLUG
6
703703
Bolt, Flange Head M8 x 16
7
4G43-07-10788
Stud and Grommet Assy
8
702295
Nut, M5, Hex Flange Head
9
4G43-07-10763
Bolt and Grommet Assy
10
4G43-07-10625
OIL FILLER CAP BLACK LETTERING NO AM WING
11
01-85003
Retainer, Crankshaft Oil Seal
12
706648
SCREW-M6 x 22 HEX FL
13
8G43-03-11422
KIT-FRONT COVER
14
03-85067
Oil Seal, Crankshaft, Front
15
1R12-01-10434
Oil Seal, Crankshaft, Rear
16
4G43-01-10194
Slinger, Rear Seal
17
697737
BOLT & WASHER M8 M8 X 47.5 HEX FLANGE PILOT GRD 8.8 BLACK
18
702851
BOLT & WASHER M8x32 HEX FLG CONL 8
19
03-85064
Gasket, Engine Front Cover
20
03-85065
Gasket, Front Cover, Centre
21
03-85066
Gasket, Front Cover, RH
22
07-85366
Gasket, Spark Plug Hole
