Lamborghini Yedek Parça - Diablo (1990-1998) Parts - Engine Oil Pump (Valid for June 1992 Version)
Parça Kodları
No
Kod
Parça Adı
001
008582501
RETAINER RING
002
008575001
RETAINER RING
003
008502515
BEARING
004
008700624
SCREW
005
008410602
WASHER
006
008851304
DOWEL
007
008300902
STUD BOLT
007
N0444416
STUD BOLT
007
008300904
STUD
007
008300905
STUD
037
N0122094
WASHER
009
008200816
NUT
010
008700822
SCREW
011
001229182
TIMING COVER
012
008523513
BEARING
013
008574502
RETAINER RING
014
008613507
SEAL
015
008575000
RETAINER RING
016
008860508
LOCK KEY
017
008860808
KEY
018
001521899
SMALL SHAFT
019
001530837
OIL PUMP COVER
020
008603503
SEAL RING
021
008601705
SEAL
022
001530839
DRIVEN GEAR
023
001532497
GEAR
024
001228118
BUSHING
025
001526871
PLUNGER
026
001519888
SPRING
027
001524378
SPACER
028
008402604
WASHER
029
001524375
PLUG
030
001531819
SHAFT
031
001525193
SPACER
032
008601301
SEAL
033
008571901
RETAINER RING
034
001525032
PULLEY
035
008253001
PLUG
036
N0152785
WASHER
038
008602603
SEAL
039
001531818
SUPPORT - SUPPORTO
