No

Kod

Parça Adı

001

N0147519

SCREW M8X50

002

008400820

WASHER

003

004133595

LEFT CROSSRAIL

003

004133596

RIGHT CROSSRAIL

004

008611606

GASKET

005

008700846

SCREW

006

009411522

RIGTH SUPPORT

006

009411523

LEFT SUPPORT

007

004131512

CROSSRAIL

008

004135417

PANEL

027

N10718801

SCREW M6X16

010

004137167

SUPPORT - SUPPORTO SERBATOIO BENZINA

011

008400801

WASHER

012

008410820

WASHER

013

008100812

SCREW

014

004135426

PANEL

016

004133887

REINFORCEMENT

017

004135423

PANEL

018

004134333

PLUG

019

004131483

PLUG

020

004130445

PANEL

022

004130207

LEFT PANEL

022

004130206

RIGHT PANEL

023

009490205

LEFT GASKET

023

410805349

RH GASKET

024

004131085

PIN

025

007014263

RUBBER WASHER

026

004132486

PANEL

028

008612503

GASKET

029

008931407

PLUG

030

004137362

RUBBER PAD

031

004137964

FRONT RH FRAME

031

004137963

FRONT LH FRAME

032

0041004924

REAR FRAME

033

009409133

REAR LH COVERING

033

009409132

REAR RH COVERING

034

009409135

MIDDLE LH COVERING

034

009409134

MIDDLE RH COVERING

035

009409137

FRONT LH COVERING

035

009409136

FRONT RH COVERING
