No

Kod

Parça Adı

-

191653

L.H. UPPER RUBBER THICKNESS

-

191651

L.H. LOWER RUBBER THICKNESS

1

186007

R.H. FUEL TANK

2

186014

L.H. FUEL TANK

3

187709

PIPE ON TANK FOR QUICK CONNECTION

4

190874

TANKS AIR BELL CONNECTION PIPE

5

187665

THREADED PLUG

6

187164

TANK LOWER CONNECTING PIPE

14

10718670

Collar

8

190517

DISAREATOR

9

192020

VENTILATION VALVE COMLETE OF TUBE

10

192007

MULTIFUNCTIONAL VALVE COMPLETE OF TUBE

11

192251

UNIONS COMPLETE TUBE

12

187494

PIPE ON TANK FOR FUEL FILL

13

192261

UNION TANKS CONNECTING PIPE

15

188799

UNION

16

235256

GASKET

17

13276477

SCREW

28

11197774

Washer

19

244747

COMPLETE RING

20

195666

COMPLETE RING

21

186172

CLIP

22

66761100

FUEL INLET LID FLANGE

23

190424

RUBBER THICKNESS

24

191656

R.H. UPPER RUBBER THICKNESS

25

191657

R.H. LOWER RUBBER THICKNESS

26

190425

RUBBER THICKNESS

27

85833700

Screw

29

168133

Screw

30

139512

BRACKET WITH SHEATH

31

189927

SPACER

32

196657

PIPE FROM PAN TO 3 WAY

33

196658

PIPE FROM VALVE TO 3 WAY

34

195439

THREE-WAY UNION

35

13432270

Collar for Hose Union

36

13433570

COLLAR FOR HOSE UNION

37

196656

PIPE FROM 3 WAY TO BOTTOM

38

104919

RING NUT

39

64872000

PIPE CONNECTOR

40

65064500

GASKET

41

177553

Clamp

42

197000

FLANGE FOR EXHAUST

43

197001

GASKET

44

199428

UNION PROTECTION

45

14457589

O.R. GASKET

46

14458289

O.R. GASKET

47

198238

PIPE PROTECTION
