No

Kod

Parça Adı

-

66847500

L.H. LONGITUDINAL SPRAG

-

66846800

R.H. TRANSVERSE SPRAG

1

66761700

UPPER CROSS MEMBER

2

66846900

L.H. TRANSVERSE SPRAG

54

14306924

SCREW

55

14496524

Washer

56

127496

Washer

6

16044524

SCREW

47

14040711

NUT

9

186312

R.H. FUSION FOR SUSPENSION CONNECTION

10

186313

L.H. FUSION FOR SUSPENSION CONNECTION

11

13547724

STUD

12

160971

CENTERING DOWEL

35

133216

NUT

32

126648

Washer

15

67370700

SPRAG

16

10717377

NUT

17

148768

BALL JOINT

18

67592600

L.H. THREADED NUT

19

148769

BALL JOINT

20

66649100

BUSHING

21

66650600

FORK CONNECTION SPRAG

22

66650700

SCREW

36

12626024

WASHER

26

67254400

SCREW

27

12646678

WASHER

29

66647200

COMPLETE FORK CONNECTION SPRAG

30

66649300

SCREW

34

13546635

Semi crankcase securing stud

37

15541124

SCREW

38

191959

NUT

39

14496724

WASHER

40

14499624

WASHER

41

67089600

LOWER CROSS MEMBER

42

14306374

SCREW

43

14499421

WASHER

45

66586800

R.H. REAR FRAME

46

66586700

L.H. REAR FRAME

48

13543324

Stud -Valid for gearbox

50

16043634

SCREW

53

66847400

R.H. LONGITUDINAL SPRAG

57

191481

STUD
