No

Kod

Parça Adı

37

139439

Sealing ring -Valid after

-

11000924

Stud bolt

1

125456

Clutch housing, complete

2

16044024

SCREW

18

12601374

Washer

4

125537

Dowel

5

121797

Bush for bearing

6

121806

Inspection cover

7

11000824

Stud -Q.ty 4 for USA-

8

15896470

NUT

9

12601174

Washer

10

114603

Timing reference bracket

11

10977624

SCREW

40

127493

WASHER

13

148604

THREADED UNION

14

10261460

Gasket

15

123865

Dowel

16

13543424

STUD BOLT

46

14040711

NUT

19

136568

Union

20

152954

BLEED SCREW

21

144259

Flexible hose

22

123478

Clamp

29

136807

Clutch Ø 8" 1/2 compl.

24

13544231

Stud

25

136813

Spacer (supplied only with unit 136807)

26

136811

Clutch disc

27

136809

Ring (supplied only with unit 136807)

28

136812

Clutch disc

30

136810

Cover (supplied only with

31

84653800

WASHER

47

127496

Washer

33

133989

NUT

34

70000568

Thrust bearing

35

123359

Bush for bearing

36

139440

Sealing ring

38

123110

Safety ring

39

10977521

SCREW

41

123696

Plate

42

123360

Sleeve for bush

43

65928500

THREADED PLUG

44

233118

O-RING

45

121717

Pre load spring

48

13516624

STUD BOLT

49

138680

Sealing ring

50

121814

Sealing ring

51

123689

Clutch shaft

52

126223

Bearing

53

149576

Pipe

54

149577

Bracket

55

10441290

BRACKET WITH SHEATH

56

10977524

SCREW

57

127494

Washer

58

139921

BLOCK
