No

Kod

Parça Adı

19

132357

Set of pistons rings

-

106184

1st undersize 0,254 mm. on Ø

-

106185

2nd undersize 0,508 mm on Ø

-

104025

2nd undersize 0,508 mm on Ø

-

113984

SHIM 1st OVERSIZE mm 0.127

-

100147

SHIM 2nd OVERSIZE mm 0.250

-

100120

2nd undersize 0,508 mm on Ø

-

100123

1st undersize 0,254 mm. on Ø

-

100124

2nd undersize 0,508 mm on Ø

-

153214

HALF BEARING SET - 1st UNDERSIZE mm. 0,254

-

100119

1st undersize 0,254 mm. on Ø

1

133144

Crankshaft

2

163528

THREADED PLUG

3

100118

UPPER HALF BEARING

4

100122

LOWER HALF BEARING

5

104023

UPPER AND LOWER HALF BEARING

6

4150813

Shim for rear support

7

10206020

Tongue

9

122064

Connecting rod, complete

10

100156

CONNECTING ROD TIGHTENING SCREW

11

104011

CONNECTING ROD TIGHTENING NUT

12

106183

CONNECTING ROD HALF BEARING

13

121974

Bush for gudgeon pin

14

121975

Gudgeon pin

15

100174

Ring for gudgeon pin

16

133023

Piston with piston rings set

17

121954

Driving sprocket for timing sys.

20

119851

ROF scraper ring (3rd groove)

21

138793

SCREW

22

138792

WASHER

23

103877

Shaft Bearing

24

132350

Engine flywheel

25

201755

Screw

26

215963

WASHER

27

123317

Dowel

28

200323

Gasket

29

132933

Driving gear for scavenage pump

30

133308

Torsion damper with pulley

31

14723320

Tongue
