Ferrari Yedek Parça - F50 - OIL/WATER PUMP - BODY AND ACCESSORIES
Parça Kodları
No
Kod
Parça Adı
34
14039614
NUT
9
168200
THERMOSTAT
1
162829
WATER DELIVERY TUBE TO CRANKCASE
2
231617
Screw
33
11197774
Washer
14
12639724
Washer
5
154191
Gasket
6
141068
UNION
7
164339
WATER PUMP BODY
8
137873
Gasket
10
164493
GASKET
11
164424
THERMOSTATIC VALVE COVER
12
231619
SCREW
15
13540924
STUD BOLT
16
10720121
Nut
19
161619
GASKET
20
164360
PUMPS INTERMEDIATE BODY
58
106352
WASHER
57
10569474
Washer
23
149537
SCREW
24
149769
STUD
46
12604474
WASHER
26
14040711
NUT
27
149768
STUD
28
14306624
Screw
45
127496
Washer
31
155048
R.H. RECOVERY OIL PUMP BODY
32
10901921
SCREW
35
155083
CENTRAL RECOVERY OIL PUMP BODY
42
11500224
STUD BOLT
37
102032
ALIGNMENT DOWEL
38
167135
O.R Gasket
39
155049
L.H. RECOVERY OIL PUMP BODY
40
150302
Gasket
41
160566
DELIVERY OIL PUMP BODY
43
104628
GEARBOX THERMISTOR
44
14359324
SCREW
47
135940
Comp. Oil Pressure Transmitter
48
129322
PRESSURE VALVE CAP
49
10257460
GASKET
50
137614
SPRING
51
160705
REGISTER
52
160505
UNION
53
197654
Oil Filter Cartridge
54
9162535
THREADED PLUG
55
111000
O.R. GASKET
56
149538
SCREW
59
162517
O.R. GASKET
60
10259960
GASKET
61
152054
GASKET
