No

Kod

Parça Adı

-

112127

DITTO THICKNESS mm. 0.9

-

112129

DITTO THICKNESS mm. 1.1

-

112130

DITTO THICKNESS mm. 1.2

-

112131

DITTO THICKNESS mm. 1.3

-

171351

WASHER THINCKNESS mm. 0,8

-

170030

PEDAL ADJUSTEMENT PIN

49

141399

SCREW

-

169362

SCREW COLLAR

-

169430

CLUTCH CONTROL PUMP

30

68313900

PLATE

-

13543524

STUD BOLT

14

170083

PEDAL SUPPORT

1

163236

CLUTCH PEDAL

2

152847

CLUTCH PEDAL DRILLED PLATE

3

14441434

SCREW

47

14039614

NUT

52

14040711

NUT

17

12638524

WASHER

7

130926

SCREW

26

145482

BALL JOINT

59

312592

NUT

60

152620

PEDAL ADJUSTEMENT PIN

11

152562

PIN FOR PEDALS

12

128612

Bush pedal (As option Nr. 128613)

13

152808

CLUTCH PEDAL BACK RETURNING SPRING

15

112166

FLEXIBLE PIN

64

12429524

STUD

19

163235

BRAKE PEDAL

20

152848

BRAKE PEDAL DRILLED PLATE

23

152565

SPACER

32

16102314

NUT

25

12429324

STUD

27

163560

SPACER

28

152632

PIN

29

152561

CONTROL LEVER FOR SWITCH

31

133555

PUSHBUTTON SWITCH

33

175211

Clutch master cylinder

34

12601374

Washer

36

13432070

Collar for Hose Union

37

154888

PIPE FROM TANK TO CLUTCH PUMP

38

13423379

ELASTIC COLLAR

39

152564

BRAKE PUMP KNUCKLE

40

154995

BRAKES CONTROL PUMP

41

154886

PIPE FROM TANK TO FRONT BRAKES PUMP

42

154887

PIPE FROM TANK TO REAR BRAKES PUMP

43

154884

OIL TANK

44

154885

PUMP SUPPORT BRACKET

45

14305324

SCREW

46

12639724

Washer

48

163557

ACCELERATOR PEDAL ASSEMBLY

50

152566

SELF LUBRICATING BUSHING

51

10730321

WASHER

53

157575

RING

54

164966

ACCELERATOR CONTROL LEVER

55

10123811

BALL JOINT HEAD

56

15896470

NUT

57

154379

ACCELERATOR CABLE

58

174001

SPRING CLIP

61

164600

SUPPORT FOR ACCELERATOR CABLE

62

168981

COUNTER NUT

63

12544574

WASHER

65

112128

DITTO THICKNESS mm. 1.0

66

184497

CONNECTOR

67

175189

SEAT RING
