No

Kod

Parça Adı

01

400117098A

BRACKET

02

N902322

SCREW

03

N90847901

NUT M6

04

07L117413C

HOSE

05

07L115687A

HOSE

06

N10451402

SCREW M6X16

07

N90265703

NUT M6X7.6

08

400115339A

HEAT SHIELD

09

400115707

CONNECTOR

10

07L115655

LH PIPE

11

N10233401

CLAMP 16.2 X 7 X 0.60

13

07L115311C

PLUG

14

07L115664C

PIPE

16

N90107203

CLAMP 12 X 8.0 X 0.5

17

357711798

RUBBER SEAL

18

N10005104

SCREW M8X35

19

07L115373B

OIL TANK

20

400115341B

HEAT SHIELD

21

N10156305

SCREW M6X12

22

07L115333B

RUBBER BUFFER

23

N138486

WASHER A16X22

24

N160282

OIL DRAINAGE M16X1,5

25

07L919501A

Water Temperature Sensor

26

07L115659

OIL SUCTION ROSE

27

07L115689B

PIPE

28

N91107101

WASHER

29

07L115688B

OILPIPE

30

400117335

COOLER EXIT CONE

31

418864929

PROTECTION

32

400117097A

BRACKET

33

400317025

LH CONVEYOR

34

07L117015B

OIL COOLER

35

07L133741

SUPPORT

36

07L115255

FLANGE

37

WHT000759

STUD BOLT (M6X14)

38

N10129201

O-RING

39

1J0711795

SPACER

40

400422095

FAIRLEAD

41

07L115333

RUBBER BUFFER

42

N90937701

CLAMP
