No

Kod

Parça Adı

01

400505183

SCREW

02

400407171B

BUSHING

03

400505179B

SPACER

20

N90323704

NUT

05

400505323B

UPPER ARM

06

N91062101

STUD BOLT

07

N91062001

STUD BOLT

08

N90226404

NUT M8

09

400407379C

2 MM SHIM

09

400407379A

1 MM SHIM

09

400407379F

0.3 MM SHIM

09

400407379E

3 MM SHIM

09

400407379B

1.5 MM SHIM

09

400407379D

2.5 MM SHIM

09

400407379

0.5 MM SHIM

10

400505311B

LOWER ARM

11

400511409

REAR STABILIZER BAR (UNTIL THE VIN 4LA01398)

11

400511409B

REAR STABILIZER BAR (FROM VIN 4LA01399)

12

400511324C

BUSHING

13

400411031H

STABILIZER BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)

13

400411031D

U-BOLT

14

WHT000923

SCREW M6X52

15

WHT001197

WASHER

16

400505465A

CONNECTING ROD (UNTIL THE VIN 6LA03288)

18

N10286102

NUT (UNTIL THE VIN 6LA03288)

22

N10314503

SCREW (UNTIL THE VIN 6LA63288)

23

N10268602

NUT

24

400505119

SCREW

25

400407749

0.5 MM SHIM

25

400407739

1.0 MM SHIM

25

400407740

1.5 MM SHIM

25

400407742

2.0 MM SHIM

26

400411175A

SPACER
