No

Kod

Parça Adı

1

317034

COMPL. RH AIR FILTER BOX

1

302631

COMPL. RH AIR FILTER BOX

1

317032

COMPL. RH AIR FILTER BOX

1

302627

COMPL. RH AIR FILTER BOX

2

317035

COMPL. LH AIR FILTER BOX

2

302632

COMPL. LH AIR FILTER BOX

2

317033

COMPL. LH AIR FILTER BOX

2

302630

COMPL. LH AIR FILTER BOX

3

842756

AIR FILTER

3

285041

AIR FILTER

4

317029

RH FILTER BOX COVER

4

302626

RH FILTER BOX COVER

5

317031

LH FILTER BOX COVER

5

302629

LH FILTER BOX COVER

6

303952

RH INLET DUCT

7

303951

LH INLET DUCT

8

250755

BRACKET

9

285553

VIBRATION DAMPER

10

12643724

WASHER

11

127494

Washer

12

14039614

NUT

13

231617

Screw

14

298773

ADHESIVE FOAM

52

85833700

Screw

53

12637824

WASHER

17

168698

Nut

18

11566524

Screw

19

231619

SCREW

20

86499510

AIR DUCT

20

85861910

AIR DUCT

21

86559900

RH AIR DUCT PARTITION

21

85902400

RH AIR DUCT PARTITION

22

86560000

LH AIR DUCT PARTITION

22

85902500

LH AIR DUCT PARTITION

23

85736200

RH DUCT FOR COOLING FRONT BRAKES

24

85736300

LH DUCT FOR COOLING FRONT BRAKES

25

86039700

CENTRAL DUCT CROSS PIECE

26

10397380

CABLE GROMMET

27

86039600

CENTRAL DUCT

28

86020900

RH AIR DUCT FASTENER CALIPER COVER

29

86021000

LH AIR DUCT FASTENER CALIPER COVER

30

86021100

UPPER PAD FOR AIR DUCT CALIPER COVER

31

86021200

LOWER PAD FOR AIR DUCT CALIPER COVER

32

86065900

COMPL. RH REAR FLANK MESH

33

86066000

COMPL. LH REAR FLANK MESH

34

85932900

LH REAR BRAKE COOLING PIPE COWL MOULDING

35

86066100

COMPL. ADAPTER FOR DUCT ON REAR FLANK

36

85692000

SCREW

36

14304387

SCREW

36

14304121

SCREW

37

12638178

Washer

38

14042177

NUT

39

10519424

WASHER

40

81923100

Screw

47

85077900

SCREW

45

65545900

WASHER

45

13550225

WASHER

46

85882500

WASHER

44

85629300

SCREW

48

83750200

SCREW

49

12638524

WASHER

50

14306474

SCREW

51

285494

SCREW

54

85739500

WASHER

55

302245

RH INLET DUCT

56

302246

LH INLET DUCT

57

302240

GASKET

58

302238

SURROUND

59

63343400

Screw

60

304435

WASHER
