No

Kod

Parça Adı

1

286140

OIL-WATER HEAT EXCHANGER

2

290681

RUBBER PIPE FOR FRONT WATER DELIVERY CONNECTOR HOSE

3

286124

WATER HEAT EXCHANGER DELIVERY RIGID PIPE

4

290544

FRONT WATER RETURN RUBBER PIPE

5

286147

WATER HEAT EXCHANGER RETURN RIGID PIPE

6

286367

COMPL. BRACKET

7

285869

RIGID PIPE FOR FRONT DELIVERY CONNECTOR HOSE

8

301840

WATER RADIATOR

9

303656

COIL MOUNT

10

303019

POWER STEERING FLUID COOLING COIL

11

295491

AC CONDENSER MOUNTING BRACKET

12

303020

ELECTRIC FAN COWL

13

302115

LOWER RH RADIATOR FORK

13

302114

LOWER LH RADIATOR FORK

14

305747

SHIM

14

305746

SHIM

14

305745

SHIM

14

305744

SHIM

14

305743

SHIM

15

282616

RUBBER HOSE BETWEEN RADIATOR AND UNDERFLOOR PIPE

16

288364

RUBBER WATER DELIVERY PIPE FROM THERMOSTAT

17

291670

WATER RETURN RUBBER PIPE ON PUMP

18

310879

UNDERBODY WATER RETURN PIPE

18

291672

UNDERBODY WATER RETURN PIPE

19

310880

UNDERBODY WATER DELIVERY PIPE

19

283850

UNDERBODY WATER DELIVERY PIPE

20

180137

Temperature Sensor

21

293041

INSULATED PIPE

34

262111

Collar

23

122791

GASKET

24

231617

Screw

27

302725

ERGAL SCREW

33

231618

Screw

29

14040614

Nut

30

250888

GASKET

31

231619

SCREW

32

291225

BRACKET WITH SHEATH

35

14039614

NUT

36

197584

Rubber Bushing

37

302296

BUSHING

38

282569

RADIATOR MOUNTING RUBBER BUSH

51

15896470

NUT

40

302574

ERGAL SCREW

48

85833700

Screw

42

262836

Condenser

43

14039511

NUT

44

303655

SPACER

45

282780

RADIATOR FASTENER BUSH

46

12643724

WASHER

47

14300534

SCREW

49

298510

SCREW

50

299688

TITANIUM SCREW

52

293067

PILLORY BLOCK FOR UNDERBODY PIPES

53

262114

Collar

54

249161

SCREW

55

303491

BRACKET

56

296125

LOWER BRACKET FOR UNDERBODY PILLORY BLOCK

57

303492

BRACKET

58

296126

UPPER BRACKET FOR UNDERBODY PILLORY BLOCK

59

14301424

SCREW

60

14440621

SCREW

61

296782

SCREW COLLAR

62

262383

COLLAR

63

294872

ELECTRIC FAN COWL SEAL

64

303405

FLAP

65

294870

ELECTRIC FAN COWL SEAL

66

295420

BRUSHLESS MOTOR FAN

67

302657

ERGAL SCREW

68

294866

FRONT FOAM

69

302481

LATERAL FOAM
