No

Kod

Parça Adı

1

3Y5867329

trim top header

10

4A0867276A

clamp, F 3Y-E-019 867>> 3Y-E-019 941, F ZH-E-019 867>> ZH-E-019 941, F 3Y-E-001 000>> 3Y-E-017 830, F ZH-E-001 000>> ZH-E-017 830, F 3Y-F-000 000>>, F ZH-F-000 000>>

3

3Y5 868 518 A

moulded headlining (leather)

12

7M3827649

clamp, F >> 3Y-D-018 900, F >> ZH-D-018 900, F 3Y-E-017 831>> 3Y-E-019 866, F ZH-E-017 831>> ZH-E-019 866

5

3Y5 867 067 C

roof bow

5

3Y5 867 067 D

roof bow, Vanity mirror

6

3Y5 867 068 C

roof bow

6

3Y5 867 068 D

roof bow, Vanity mirror

7

N90930201

tapping screw, D >> - 08.02.2016

34

N0454275

speed nut

9

3Y5 867 500 A

moulded headlining (leather)

9

3Y5 867 500 B

moulded headlining (leather)

11

3Y5 863 565 A

moulded headlining

11

3Y5 863 764

moulded headlining

13

N90959101

speed nut, included in position:

16

3Y5 868 680 C

overhead console

16

3Y5 868 726 A

overhead console

25

N90562401

tapping screw, fill. hd.

26

3Y0 857 477

bracket

27

3Y5 867 460

trim stripe

28

N10613301

Hexagon socket flat, head bolt

29

N91135001

clamping washer, only to be used with:, D - 02.03.2015>>

22

3Y5857503

trim for interior light

22

3Y5857503B

trim for interior light

31

N90698605

hexagon socket head panel bolt

24

3Y5 868 679 C

overhead console

24

3Y5 868 725 A

overhead console

30

3Y5858122

trim for interior light

30

3Y5858122A

Trim for interior light

32

6Q0868243

clip

33

3Y5 867 268 A

retaining clamp

35

N90434903

hex. nut with washer
