No

Kod

Parça Adı

1

3Y5 867 329 B

top header

6

4A0867276A

clamp, F 3Y-E-019 867>> 3Y-E-019 941, F ZH-E-019 867>> ZH-E-019 941, F 3Y-E-001 000>> 3Y-E-017 830, F ZH-E-001 000>> ZH-E-017 830, F 3Y-F-000 000>>, F ZH-F-000 000>>

3

3Y4 868 518 A

moulded headlining

3

3Y4 868 518 C

moulded headlining

8

7M3827649

clamp, F >> 3Y-D-018 900, F >> ZH-D-018 900, F 3Y-E-017 831>> 3Y-E-019 866, F ZH-E-017 831>> ZH-E-019 866

5

3Y4 867 500 A

moulded headlining

7

3Y5 863 764

moulded headlining

9

N90959101

speed nut, included in position:

12

3Y5 868 726 A

overhead console

13

N90562401

tapping screw, fill. hd.

14

3Y0 857 477

bracket

21

3Y5 867 460

trim stripe

22

N10613301

Hexagon socket flat, head bolt

25

N90698605

hexagon socket head panel bolt

18

3Y5857503

trim for interior light

18

3Y5857503B

trim for interior light

19

N91135001

clamping washer, only to be used with:, D - 02.03.2015>>

20

3Y4 868 725 A

overhead console

23

N10334801

shouldered hex. nut,, self-locking, F >> 3Y-C-017 366, F >> ZH-C-017 366

24

3Y5858122

trim for interior light

24

3Y5858122A

Trim for interior light

30

N90434903

hex. nut with washer

27

3Y4 867 268

retaining clamp

28

6Q0868243

clip

29

5G0 867 289 A

clamp
