No

Kod

Parça Adı

1

A3Y5839901B

b-pillar cover plate, D >> - 08.11.2010

1

3Y5 839 901 D

b-pillar cover plate, D - 26.05.2014>>

1

A3Y5839902B

b-pillar cover plate, D >> - 08.11.2010

1

3Y5 839 902 D

b-pillar cover plate, D - 26.05.2014>>

1

3Y5 839 890 D

b-pillar cover plate, D - 26.05.2014>>

1

3Y5 839 889 D

b-pillar cover plate, D - 26.05.2014>>

2

3Y5839211A

adjustment part

3

3Y5853131B

adjuster unit, stud, D - 11.04.2011>>

4

N91185301

Hexagon socket head, bolt, D >> - 14.04.2014

4

N10621601

Hex socket oval head collared, D - 04.11.2013>>

5

3Y5839979D

protective strip for door

5

3Y5839980D

protective strip for door

6

3Y5 839 477 B

rubber seal, D - 27.08.2012>>

6

3Y5 839 478 B

rubber seal, D - 27.08.2012>>

7

3Y5 839 541

trim strip for waistline, D - 07.12.2015>>

7

3Y5 839 542

trim strip for waistline, D - 07.12.2015>>

8

N10586402

socket head hexagon bolt with cone

11

3Y5839371F

trim for door window frame, D - 26.05.2014>>

11

3Y5839372F

trim for door window frame, D - 26.05.2014>>

12

3Y5 837 889 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 890 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 901 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 902 D

b-pillar cover plate, D - 26.05.2014>>

13

3Y5837373C

trim stripe for door

13

3Y5837374C

trim stripe for door

14

N90626204

oval hexagon socket head bolt

15

3Y5 837 477 B

rubber seal, D - 27.08.2012>>

15

3Y5 837 478 B

rubber seal, D - 28.08.2012>>

16

3Y5837372E

trim for door window frame, D - 26.05.2014>>

16

3Y5837371E

trim for door window frame, D - 26.05.2014>>

17

3Y5 837 541 A

trim strip for waistline, D - 19.12.2016>>

17

3Y5 837 542 A

trim strip for waistline, D - 19.12.2016>>

18

N91187101

hexagonal socket head, screw

19

3Y5837643B

trim stripe for fender, D >> - 10.11.2014

19

3Y5 837 643 C

trim stripe for fender

19

3Y5837644B

trim stripe for fender, D >> - 10.11.2014

19

3Y5 837 644 C

trim stripe for fender

20

3Y5 839 637 C

trim strip for, rear panel, D - 20.07.2015>>

20

3Y5 839 638 C

trim strip for, rear panel, D - 20.07.2015>>

21

3Y0 837 067

track, D - 11.06.2012>>

21

3Y0 837 068

track, D - 11.06.2012>>

22

3Y0 839 067

track, D - 11.06.2012>>

22

3Y0 839 068

track, D - 11.06.2012>>

23

3Y5 853 893 A

gasket

23

3Y5 853 894 A

gasket
