No

Kod

Parça Adı

1

3Y5 839 901 D

b-pillar cover plate, D - 26.05.2014>>

1

3Y5 839 889 D

b-pillar cover plate, D - 26.05.2014>>

1

3Y5 839 902 D

b-pillar cover plate, D - 26.05.2014>>

1

3Y5 839 890 D

b-pillar cover plate, D - 26.05.2014>>

2

3Y5839211A

adjustment part

3

3Y5853131B

adjuster unit, stud, D - 11.04.2011>>

4

N10621601

Hex socket oval head collared, D - 04.11.2013>>

5

3Y5839979D

protective strip for door

5

3Y4 839 979 A

protection strip for door

5

3Y5839980D

protective strip for door

5

3Y4 839 980 A

protection strip for door

6

3Y5 839 477 B

rubber seal, D - 27.08.2012>>

6

3Y4 839 477

rubber seal

6

3Y5 839 478 B

rubber seal, D - 27.08.2012>>

6

3Y4 839 478

rubber seal

7

3Y5 839 541

trim strip for waistline, D - 07.12.2015>>

7

3Y4 839 541

trim strip for waistline

7

3Y5 839 542

trim strip for waistline, D - 07.12.2015>>

7

3Y4 839 542

trim strip for waistline

8

N10586402

socket head hexagon bolt with cone

9

N90880204

shouldered hex. nut,, self-locking

18

N91187101

hexagonal socket head, screw

11

3Y5839371F

trim for door window frame, D - 26.05.2014>>

11

3Y4839371B

trim for door window frame

11

3Y5839372F

trim for door window frame, D - 26.05.2014>>

11

3Y4839372B

trim for door window frame

12

3Y5 837 889 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 901 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 890 D

b-pillar cover plate, D - 26.05.2014>>

12

3Y5 837 902 D

b-pillar cover plate, D - 26.05.2014>>

13

3Y5837373C

trim stripe for door

13

3Y5837374C

trim stripe for door

14

N90626204

oval hexagon socket head bolt

15

3Y5 837 477 B

rubber seal, D - 27.08.2012>>

15

3Y5 837 478 B

rubber seal, D - 28.08.2012>>

16

3Y5837372E

trim for door window frame, D - 26.05.2014>>

16

3Y5837371E

trim for door window frame, D - 26.05.2014>>

17

3Y5 837 541 A

trim strip for waistline, D - 19.12.2016>>

17

3Y5 837 542 A

trim strip for waistline, D - 19.12.2016>>

19

3Y5 839 637 C

trim strip for, rear panel, D - 20.07.2015>>

19

3Y5 839 638 C

trim strip for, rear panel, D - 20.07.2015>>

20

3Y0 837 067

track, D - 11.06.2012>>

20

3Y0 837 068

track, D - 11.06.2012>>

21

3Y0 839 067

track, D - 11.06.2012>>

21

3Y0 839 068

track, D - 11.06.2012>>
