No

Kod

Parça Adı

1

3Y0927317A

vacuum pump, D - 21.11.2011>>

2

3Y0 802 419

bracket, vacuum pump, D - 18.03.2013>>

3

06A133567K

rubber isolator

4

N10158605

bolt,hex.hd.with shoul.(combi), F 3W-C-076 377>> 3W-C-076 377, F ZA-C-076 377>> ZA-C-076 377

5

N90215804

hex. nut, F >> 3W-G-051 745, F >> ZA-G-051 745

6

3Y0612178

damping rubber

7

N90685101

bracket for connector housing, D - 20.08.2012>>

8

3Y0 612 041 C

vacuum pipe, D - 29.10.2012>>

9

N10401901

double clip

10

3D0201449K

securing clip, D >> - MJ 2016

11

3Y0 614 931 C

vacuum pipe, D - 29.10.2012>>

12

3Y0612797

clamp

13

N90943501

bracket for hose

14

3D0201449M

securing clip, D >> - 26.05.2014

15

3Y1 612 936 A

vacuum pipe, D - 29.10.2012>>

16

3Y2 612 936 A

vacuum pipe, D - 29.10.2012>>

36

N 909 264 01

spring clip

18

3Y0 612 930 D

vacuum pipe, D - 21.02.2013>>

19

07C133529

non-return valve

20

3W0612391M

clamp, Only in combination with:, Only in combination with:

35

N90770201

spring clip, F 3Y-D-017 738>>, F ZH-D-017 738>>, D >> - 21.02.2013

20

N10255501

retaining clip, Only in combination with:

35

N90686701

spring clip, Only in combination with:, Only in combination with:

36

N0245097

clamp, F 3Y-D-017 738>>, F ZH-D-017 738>>, D >> - 21.02.2013

22

N10259903

clamp, F >> 3Y-D-017 737, F >> ZH-D-017 737

22

N0206253

clamp, F 3Y-D-017 738>>, F ZH-D-017 738>>

23

3Y0 612 929 D

vacuum pipe, D - 21.02.2013>>

24

N0206245

clamp, F >> 3Y-D-017 737, F >> ZH-D-017 737

24

N0206473

clamp, F 3Y-D-017 738>>, F ZH-D-017 738>>

25

N90737101

Oval hexagon socket head bolt, F >> 3W-D-085 442, F >> ZA-D-085 442

26

6Q0611933A

non-return valve

27

N10201801

retaining clip, F >> 3Y-D-017 737, F >> ZH-D-017 737

27

N10202001

Ear Hose Clamp, F 3Y-D-017 738>>, F ZH-D-017 738>>, D >> - 21.02.2013

27

N 102 556 01

retaining clip, D - 21.02.2013>>

28

3W0612413

heat shield

29

3Y0612935

vacuum pipe, D >> - MJ 2015

29

3Y0 612 935 B

vacuum pipe, D - MJ 2016>>

30

443131541

vacuum reservoir

31

N10017304

shouldered hex. nut, D >> - 03.01.2011

32

N10128802

double clip

33

N10573601

retainer, swivelling

36

4G0 145 917

spring clip, D - 21.02.2013>>
