No

Kod

Parça Adı

1

3Y0 955 449 G

fluid container, contains:

2

3W0955455B

sealing cap

4

N90167003

hexagon screw with washer

5

3Y0955651A

windscreen washer system pump

6

3Y0 955 681 A

headlamp, water pump

8

3Y0955462B

water filler neck, assembly, contains:

9

3Y0955465

grommet

9

3Y0 955 465 A

grommet

10

3Y0955487A

water filler neck, tube

11

3Y0 955 964 J

windscreen washer fluid line, reservoir, windshield glass

12

3Y0 955 964 K

water hose, For mounting to:, Cover for plenum chamber

13

3Y0 955 970 P

Hose, headlamp, reservoir

15

3Y0 955 970 Q

Hose

16

3Y0 955 970 R

Hose

17

3Y0 955 978 D

pressure cylinder with jet, carrier and jet

18

3Y0 955 979 D

pressure cylinder with jet, carrier and jet

19

3D0955986A

heated spraying jet

20

3Y0 955 927 A

cover

21

3Y0 955 928 A

cover

22

N10338903

bolt, hex. hd. with shoulder, F 3Y-E-018 855>> 3Y-E-019 941, F ZH-E-018 855>> ZH-E-019 941, F 3Y-E-001 000>> 3Y-E-017 830, F ZH-E-001 000>> ZH-E-017 830, F 3Y-F-000 000>>, F ZH-F-000 000>>

23

7M0919376

water level switch

24

7M0919382

seal ring

25

3W0955192

grommet

26

N90681401

corrugated pipe piece
