No

Kod

Parça Adı

002

417825349A

STEEL FRAME UPPER ELEMENT

002

417825349B

UPPER ELEMENT OF CARBON FRAME

003

417825350C

STEEL FRAME LOWER ELEMENT

003

417825350B

REAR ELEMENT OF CARBON FRAME

004

417825431A

LEFT ARM OF STEEL FRAME

004

417825431B

LEFT ARM OF CARBON FRAME

005

417825432B

RIGHT ARM OF CARBON FRAME

005

417825432A

RIGHT ARM OF STEEL FRAME

006

417810250

BUSHING (FOR CARBON FRAME)

007

417810249

BUSHING (FOR CARBON FRAME)

008

417813455

BUSHING (FOR CARBON FRAME)

009

0041016911

1.5 MM SHIM (FOR STEEL FRAME)

009

0041016930

0.5 MM SHIM (FOR STEEL FRAME)

015

0041016912

WASHER

010

N10049309

SCREW

011

0041016910

SCREW

016

0041017007

NUT

014

0041016975

SCREW

017

N90166802

SCREW

018

410810368

WASHER (FOR CARBON FRAME)

019

417801931A

BALL JOINT

020

008201035

NUT

021

417813235

MOBILE REAR CROSS MEMBER

022

N01034510

SCREW M8X45

026

N90840802

WASHER

027

008410820

WASHER

025

N0147519

SCREW M8X50

028

400407742

2.0 MM SHIM

028

400407739

1.0 MM SHIM

028

400407740

1.5 MM SHIM

028

400407749

0.5 MM SHIM
