No

Kod

Parça Adı

1

12023-06-1358-AC

Rear Tub Bonded Assy

2

12023-06-1116-AG

Front Plate, Rear Damper Tray

3

55327-0596

Screw, M10 x 1.5 x 25

4

12023-09-6114

Washer, M10 Flat ID10.5xOD20x2.0

5

12023-06-1118-AF

Rear Plate, Rear Damper Tray

6

12023-06-1174-AA

Shear Sleeve

7

12023-06-1130-AE

Centre Mount, Rear Damper

8

12023-09-6070-AA

Screw, M10 x 1.5 x 35

9

12023-06-1140-AC

Cover Plate, Rear Damper Centre Mount

10

12023-06-1144-AE

Bracket, Rear Centre V Brace

11

12023-06-1320-AA

Trim Panel, V brace Centre Node

12

12023-06-1366-AA

Spacer, Centre Damper Mount

13

12023-06-1368-AA

Sleeve, Centre Damper Mount

14

12023-06-1265-AE

End Cover Assy, Rear Damper Tray, RH

15

12023-06-1264-AE

End Cover Assy, Rear Damper Tray, LH

16

55327-0752

Screw, M5 x 0.8 x 12, CHCS

17

12023-06-1272-AB

Window Panel, Rear Damper Tray

18

55327-0750

Screw, M5-0.80 x 08, BHSC

19

12023-06-1318-AA

Spacer, Window Panel Mount

20

12023-06-1134-AC

Rocker Mount Front RH, Rear Damper Tray

21

12023-06-1132-AC

Rocker Mount Front LH, Rear Damper Tray

22

12023-06-1138-AC

Rocker Mount Rear RH, Rear Damper Tray

23

12023-06-1136-AC

Rocker Mount Rear LH, Rear Damper Tray

24

12023-09-6068

Screw, M10 x 1.5 x 30

25

12023-06-1180-AA

Shear Sleeve, ID 10.2 x 19

26

12023-06-1274-AA

Cover, Rocket Access, Rear Damper Tray

27

55327-0748

Screw, M6-1.00 x 12 Flange BHCS

28

12023-03-7124-AC

Plate, Rear Earth

29

702535

Screw M6x12 hex flg hd

30

12023-03-8504-AB

Bracket, Rear Brake Line Jumper Hose

31

M1/B23-M5x12

Stud, Big Head Bonding, M5-1.0 x 12
