No

Kod

Parça Adı

-

12023-09-1363-AA

Arm assy, Windshield Wiper, Driver side RHD

-

12023-09-1365-AA

Arm assy, Windshield Wiper, Passenger side RHD

-

AY93-37-10102

Blade assy, Windshield Wiper, Driver side, RHD

-

AY93-37-10103

Blade assy, Windshield Wiper, Passenger side, RHD

-

12023-09-1350-AD

Sensor, Windshield Wiper Arm Trigger LH

1

12023-09-1362-AG

WPR ARM ASY DRV

2

12023-09-1364-AF

Arm assy, Windshield Wiper, Passenger side LHD

3

12023-09-1052-AF

Blade assy, Windshield Wiper, Driver side, LHD

4

12023-09-1054-AF

Blade assy, Windshield Wiper, Passenger side, LHD

5

12023-09-6138

Screw M4x10 torx c/sunk hd

6

51040-080-035

Bolt M8x35 hex socket thin hd Cap

7

12023-09-1026-AH

Bracket, Retaining- Wiper Arm Position Sensor

8

12023-09-1148-AD

Hard stop, Windshield Wiper Arm

9

12023-09-1228-AC

Hard stop Upper, Windshield Wiper Arm

10

51060-050-016

Screw M5x16 hex socket c/sunk hd

11

51050-060-025

Bolt M6x25 Socket hd Cap

12

51416-060-001

M6 Washer, Flat Type Z ID6.4xOD12

13

51729-060-001

Nut M6 hex, nylon insert

14

12023-09-1022-AG

Trigger ring, Wiper Arm

15

51260-060-008

Screw M6x8 hex socket set, cup point

16

12023-09-1050-AA

Bushing, Windshield Wiper Arm Hub

17

12023-09-1351-AD

Sensor, Windshield Wiper Arm Trigger RH
