No

Kod

Parça Adı

34

51 43 7250617

Slot cover, left

34

51 43 7250618

Slot cover, right

1

51 43 7250585

Lateral trim panel, left

1

51 43 7250586

Lateral trim panel, right

2

51 43 7115722

Clip, bottom part

3

51 41 7067459

Trim, high-range speaker

4

65 13 6919363

TOP-HIFI LOUDSPEAKER TWEETER

5

07 14 7117570

Fillister head self-tapping screw

12

07 14 6981256

Body nut

7

51 41 7067457

Trim, mid-range speaker

8

65 13 0420684

Loudspeaker HiFi, mid-range

9

07 14 6949299

Self-locking hex nut

10

07 14 9144232

Insert

11

51 43 7250587

Trim, storage compartment, left

11

51 43 7250588

Trim, storage compartment, right

13

51 45 7057952

Screw

14

51 16 7072533

Spring clip

15

07 14 7110847

Clip, bottom part

16

51 42 7068472

Sleeve

17

54 10 7055524

Screw

18

51 41 9127379

Velcro fastener

19

51 43 9180777

Adapter, top shoulder, left

19

51 43 9180778

Adapter, capping, right

20

51 43 6985045

Sound insulation, rear left

20

51 43 6985046

Sound insulation, rear right

21

51 43 9111265

BRACKET REAR LEFT

21

51 43 9111266

BRACKET REAR RIGHT

22

51 40 7250584

Handle

23

51 43 7249663

Capping, outer left

23

51 43 7249664

Capping, outer right

23

51 43 9113835

Capping, outer left

23

51 43 9113836

Capping, outer right

24

51 43 9158739

Wood frame, left

24

51 43 9158740

Wood frame, right

25

07 11 9903046

Screw, self tapping

26

51 43 6964453

Disc, left

26

51 43 6964454

Disc, right

27

51 43 6981721

Support, left

27

51 43 6981722

Support, right

28

51 43 8267321

Clip, upper part

29

41 61 8172499

Fillister head screw

30

51 41 7046415

Clip Natur

31

07 12 9904859

Hex nut

32

51 24 8193848

Screw

33

51 43 9115553

Seals, left

33

51 43 9115554

Seals, right

36

51 43 9169076

Adapter, side trim panel
