No

Kod

Parça Adı

1

11 37 7521587

Eccentric shaft

2

11 37 7500978

Needle bearing

3

11 37 7503085

Lever with roller

3

11 37 7503093

Lever with roller

4

07 12 9903535

Torx bolt

5

11 37 7512183

Spring support

5

11 37 7512184

Spring support

6

07 12 9903532

Torx bolt

7

11 37 7504774

RETAINER SPRING

7

11 37 7504775

RETAINER SPRING

8

11 37 7534164

Magnetic wheel

9

07 11 9903465

Fillister-head screw f magnetic wheel

10

11 37 7527017

Eccentric shaft sensor

11

07 12 9905262

Isa screw with washer

12

11 42 7521999

Oil spray tube, inlet side

12

11 42 7522001

Oil spray tube, inlet side

13

11 42 7522000

Oil spray tube, outlet side

13

11 42 7522002

Oil spray tube, outlet side

14

11 42 7515297

Oil spray tube, outlet side

14

11 42 7515300

Oil spray tube, outlet side

15

11 42 7515301

O-ring

16

11 31 7527593

Hex Bolt

17

11 12 7521106

Twist protection

18

11 42 7507967

Fixing clamp

19

11 42 7512942

Hex Bolt
