No

Kod

Parça Adı

1

64 50 0303141

Pipe, suction air conditioning

1

64 50 0303143

Pipe, suction air conditioning

1

64 50 0399224

Pipe, suction air conditioning

1

64 50 0399323

Pipe, suction air conditioning

2

64 50 0303142

Pipe assy, air conditioning

2

64 50 0303144

Pipe assy, air conditioning

2

64 50 0399225

Pipe assy, air conditioning

2

64 50 0399324

Pipe assy, air conditioning

3

64 50 0303145

Pipe assy, air conditioning

4

64 50 0303146

Pipe assy, air conditioning

5

64 50 0303147

Pipe assy, air conditioning

5

64 50 0303149

Pipe assy, air conditioning

6

64 50 0303148

Pipe assy, air conditioning

6

64 50 0303150

Pipe assy, air conditioning

7

64 50 0302842

Valve assy, air con

8

64 11 1380573

Plate

9

64 50 8390603

Gasket ring

10

64 50 8375741

Gasket ring

11

64 50 8390601

Gasket ring

12

64 50 8374959

Gasket ring

13

64 50 8390602

Gasket ring

14

07 11 9905720

Fillister head with washer

15

07 11 9905761

Fillister head screw

16

64 11 6910918

Set of gasket rings/mounting parts
