No

Kod

Parça Adı

1

8D33-8333-AA

HOSE - RADIATOR

2

8D33-8555-AB

TUBE ASSY-BYPASS

9

HY53-E804349-AA

M6 X 14 SCREW HEX HD

4

4G43-8C350-GB

HOS-ENG COOL RSVR A

6

4G43-19B518-BC

Tank-Asy Expansion

7

1R12-37-10166

Switch, Coolant Level

8

4G43-8101-BA

Pressure Cap Assy

10

703612

Nut & Washer, M6, HVAC to XCB

11

4G43-8C363-FC

HOSE RAD DEGAS

12

4G43-8063-AE

Hose, Engine to Supply Tank

13

4G43-8003-EB

Pipe, Cross Over Bleed

14

4G43-8003-CA

Hose, Thermo Housing, Cross Over Bleed

15

702904

Spring Clamp, Hose, 17 x 15

16

702295

Nut, M5, Hex Flange Head

17

4G43-8584-EB

HOSE ASY THERMO UPR

18

AD43-18D334-AA

HOS-HTR INLT ASSY LH

18

AD43-18D334-BA

HOS-HTR INLT ASSY RH

20

AD43-18D359-AA

HOS-HTR OLET ASSY LH

20

AD43-18D359-BA

HOS-HTR OLET ASSY RH

21

701335

Clip, Hose Spring, 20 x 15

22

4G434867BA

Cover assy, bottom

23

4G43-6793-BB

Top Cover, Engine Harness

24

700229

Bolt, M8 x 35, Hex Flange Head

25

4G43-58-AA

HOSE CLIP SPACER PLATE

26

AD43-2A155-AA

BRACKET - HOSE CLIP

27

701345

NUT M6 HEX FLG MTL 8

28

6G33-TBD2-BA

Reservoir, Coolant Expansion

29

703734

Bolt and Washer M6x25 hex hd

30

4G43-8N029-AG

Hose Assy, Overflow

31

AD43-55-AA

DOUBLE C CLIP 18

32

AD43-8B081-AA

HOSE RADIATOR SUPPLY TANK OVERFLOW

33

701181

Clip, 16 x 6.5 x 1.5-6

34

AD43-18D359-EA

HTR PIPE OLET INLET ASSY

35

AD43-18D359-DA

HTR PIPE OLET INLET ASSY

36

702901

HEAVY DUTY SPRING BAND CLAMP 23 x 15

37

702944

Nut, M6, Hex Flanged Head

38

703198

Bolt, M6 x 40, Chrome Free

39

AD43-18495-AA

Valve assy, Water Heater Control

40

AD4318D359FA

Hose, Heater Outlet, LHD

40

AD43-18D359-CA

HOSE HEATER OUTLET ASSY RHD

43

701172

Clip, 16 x 2.8 - 3.3
