No

Kod

Parça Adı

0

91950

ENGINE ASSY-DB9 08MY

1

AD436015AA

Cylinder block assy

2

01-84995

Dowel, 8 x 18

3

01-85000

Plug, 52.6 dia cup

4

01-85001

Plug, Cup Expansion

5

01-84994

Dowel, 16 x 19

16

01-84998

PLUG-PIPE 3/4x14

7

01-84997

Plug 1.26 Cup (32mm)

25

01-86452

Plug, 1/4-18 x 10.8

9

4G43-01-10819

Bolt, Main Bearing Cap

10

1R12-01-10678

CAP-CRANKSHAFT MAIN BRG-REAR

11

4G43-01-10203

Bolt, M10 x 1.5 x 91

12

4G43-01-10202

Bolt, M8 x 1.25 x 82, Hex Head

13

01-85133

Stud Bolt, Bearing Caps

14

707151

PIN-6x16 DWL CHMFR H

15

699134

Dowel, Hollow

17

7G43-6055-AA

Cylinder Liner, V12

18

8G43-6K342-BB

CRANK SENSOR HEATSHIELD

19

700606

Screw, M6 x 12, Hex Flange Head

20

8G436M099AA

Cylinder head assy LH (inc valves/springs/adjusters etc, minus cams etc)

20

8G43-6049-AA

HD ASY CYL(6.0L-V12-

21

703690

Bolt, M8 x 63, Hex Flange Head

22

06-86044

Bolt, M10 x 1.5 x 151.5, Hex Flange Head

23

01-84996

DOWEL-10x49.25

24

0185032

Plug 1- 11.5x18 Hl

26

703704

Stud, M8 x 13.6+16, Hex Head

27

06-86441

PLUG-3/8 - 18x 10.8

28

ED23-06-10174

ADAPTOR-O/PRESS SWTC

29

1R12-39-10532

Switch, Oil Pressure

30

CD33-6083-AA

Gasket, Cylinder Head, LH

30

CD33-6051-AA

Gasket, Cylinder Head, RH

31

8G439425CA

Intake, manifold assy LHS

32

8G439425DA

Intake, manifold assy RHS

33

702852

BOLT-M6x1.0x47 PT HEX FLG HD GRD 8.8

34

4G43-08-10002

Isolator, Intake, Manifold

35

1R12-08-10077-PK

Inlet Manifold Head Gasket - Pack of 2

36

8G43-9J444-AA

SUPPORT BRACE INTAKE MANIFOLD

37

702847

SCREW-M6x25 PAN INT LOB 8

38

4G43-001B46-BB

MANIFOLD BADGE

39

EG33-08-10726

SENSOR-AIR TEMP

40

4G43-2A411-AA

CARTRIDGE ASSY
