No

Kod

Parça Adı

-

8D33-9600-BA

Airbox Assembly- RHS

-

AD23-9A675-AA

ASSY - A/CLEANER INTAKE RH

-

BD23-9B609-BA

Bracket, Air Cleaner Outer, RH

-

AD23-9C623-AA

Duct Assy, Air Cleaner to Engine RH

1

8D33-9600-CA

Airbox Assembly - LHS

2

4G43-0410-AA

Screw - 5.2x32 Self Tap

3

4G43-5144-AA

Spacer, Engine Airbox Isolator

4

4G43-9697-CA

Isolator, Engine Airbox

5

4G43-9C664-AB

Gasket - Air Cleaner

6

4G43-9601-AB-PK

Air Filter Cleaner, Box of 2

7

6L34-9H465-BA

Valve assy, Therm Air Control

8

8D33-3N731-AA

VALVE HOUSING ASSEMBLY

9

8D33-5F006-AA

RIVET

10

8D33-7L576-AA

Actuator, Control Valve

11

W506941S437

Screw, M4 x 8, Pan Hd

12

8D33-2K061-AA

VACCUUM RESERVOIR

13

8D33-43836-AA

VACUUM HOSE ASSEMBLY

14

8D33-ANR1350-AA

CABLE TIE HOSE CLIP ASSEMBLY

15

AD23-9A675-BA

ASSY - A/CLEANER INTAKE LH

16

4G43-6C704-AA

O Ring - Engine Duct

17

4G43-2705-AA

Rivet, Plastic

18

4G43-9N967-AA

Grommet - ENG A/CLNR Tub EXT

19

BD23-9B609-AA

Bracket, Air Cleaner Outer, LH

20

703025

Screw, M6 x 25, Hex Flange Head

21

AD23-9C623-BB

Duct Assy, Air Cleaner to Engine LH

22

4G43-9N832-BB

CLAMP - DUCT TO MAFS DUCT

23

4G43-9N832-AA

Clamp Assy - Air Cleaner Hose

24

4G43-12B612-AB

Body - Engine Electronic Mas Air Flow Sensor

25

4G43-6C704-BA

O Ring Engine Duct interior

26

4G43-08-10933

Mass Air Flow Meter

27

4G43-0410-BB

Screw, M35 x 12 Self Tap
