No

Kod

Parça Adı

0

1R12-082823-AC

ASSY - AIRBOX

1

1R12-080741-AF

COVER - AIRBOX

2

699769

WASHER RETAINING M6

5

699820

SCREW M5x10 SKT BUTTON FLANGE

3

1R12-080742-AD

GASKET-AIRBOX COVER

4

1R12080746AG

Airbox

6

699818-PK

SCREW M6x20 SKT (10)

7

1R12-083706-AA

SPACER AIRBOX FRONT MOUNT

8

1R12-081750-AC

DUCT-AIRBOX RH

8

699707

ISOLATOR

9

1R12-081751-AC

DUCT-AIRBOX LH

10

699305

SCREW M6 X 20 SOCKET HEAD BUTTON

11

124383

WASHER 1/4 x 1 PLAIN MILD STEEL ZINC PLT

12

698979

CLIP HOSE WORM DRIVE

13

1R12-082824-AD

ASSY - DUCT AIR INTAKE RH

13

1R12-081749-AD

COLLAR-AIR INTAKE

14

1R12-082825-AD

ASSY - DUCT AIR INTAKE LH

15

1R12-632693-AA

CLIP-AIR INTAKE TUBE

16

1R12-632521-AA

BRACKET 1-AIR INTAKE TUBE LH

16

1R12-632520-AA

BRACKET 1-AIR INTAKE TUBE RH

17

697516-PK

NUT-M6 HEX BLK (10)

18

700126

SCREW M6x20 HEX FLG

19

1R12-082729-AA

GAUZE - AIRFLOW STRAIGHTENER

20

1R12-083196-AD

DUCT - INDUCTION FLEXIBLE RH

20

1R12-08-10169

SENSOR-MASS AIR FLOW

21

1R12-083197-AD

DUCT - INDUCTION FLEXIBLE LH

22

699669

CLIP - WORM DRIVE

23

1R12-121428-AC-PK

AIR FILTER-BOX OF 2

24

699525

ISOLATOR - MAFS

25

1R12-322822-AG

ASSY RADIATOR PANEL UPPER
