No

Kod

Parça Adı

1

37-85928

BATTERY-SVR CALCIUM 12V 90AH RC170mins 680AMPS (SAE)

2

1R12-370397-AE

Switch - Battery Disconnect

3

702295

Nut, M5, Hex Flange Head

4

1R12-372690-AB

INSULATOR-BATTERY DISCONNECT SWITCH

5

696680

TAPE SELF ADHESIVE 35x50M

5

692205

POP-RIVET 1/8 x3/8

6

1R12-373789-AA

REMOTE BATTERY DISCONNECT SWITCH

7

1R12370408AA

Tray assy, battery

8

1R12-371116-AB

BATTERY CLAMP-FRONT

9

1R12-375077-AB

BATTERY CLAMP REAR

42

700126

SCREW M6x20 HEX FLG

43

694567

WASHER M6 x 18 OD 0.9 THICK ZINC PLT

41

703172-PK

Screw-M8x25 Pan 8 Chrome Free Pack of 10

13

1R12-370401-AD

BATTERY +VE - BATTERY TO REAR JUNCTION BLOCK

24

699209

Tie-wrap, heat proof

14

699947

CABLE TIE

14

1R12-370402-AE

BATTERY NEGATIVE

15

37-86111

COVER-BATTERY TERM.

16

1R12-370403-AD

BATTERY +VE - REAR JUNCTION BLOCK TO BULKHEAD STUD

17

4R13-14A120-AC

CABLE-BATTERY TO STARTER

18

1R12-370404-AD

BATTERY +VE - BULKHEAD STUD TO ALTERNATOR

19

1R12-370407-AD

BATTERY +VE - REAR JUNCTION BLOCK TO LH FACIA FUSEBOX

20

1R12-370408-AE

BATTERY +VE - LH FACIA F/BOX TO RH FACIA F/BOX RHD

20

1R12-372740-AD

CABLE-LH TO RH FACIA FUSEBOX LHD

21

1R12371719AA

Cable, bulkhead to jump start terminal

22

702429

LOCKNUT M6

30

703739

Nut, M8, Hex Flange Head

27

9G43-10A752-AA

TERMINAL POST ASSY

28

697164

WASHER M8 LOCK SINGLE COIL

32

697418

NUT M8 HEX

31

37-85236

Protector, Power Stud

35

1R12-372636-AA

Tube, Battery Vent, 390mm

34

1R12-372635-AA

Tube, Battery Vent, 240mm

36

699510

ELBOW 90 DEGREES

37

37-81850

Grommet, battery vent tube

38

1R12-37-10036

CARRIER BOX

39

697398

TIESTRAP-RELEASEABLE 4.6 x 165

39

1R12-37-10210

EDGE PROTECT STRIP 169mm

39

1R12-371118-AD

BRACKET - ELECTRICAL CARRIER

40

9781846

Label, battery warning

41

703265

Screw, M6 x 16, Hex Flange Head

41

697274-PK

TIE STRAP(PK OF 100)

41

694891

P-CLIP

44

1R1E-5G261-AA

STRAP-EXH CONV PIP STAB - RH

44

1R1E-5G261-BA

STRAP-EXH CONV PIP STAB - LH

44

703169

NUT - M6 HEX FLANGE CHROME FREE
