No

Kod

Parça Adı

1

1R12-804558-AAW

ASSY FOOTREST RHD

1

1R12-804559-AAW

ASSY FOOTREST LHD

2

1R12803600AB

Pad, footrest

3

1R12-803328-AA

BRACKET - FOOTREST RHD

3

1R12-803329-AA

BRACKET - FOOTREST LHD

4

700448

Screw, M5 x 30, csk Pedal pad

4

703165

NUT M5 HEX FLG PLAS CHROME FREE

5

1R12-834478-AB

MOUNTING SILL PLATE

6

5R13-132A51-AA

SILL PLATE ASSY VEHICLE NAME VANQUISH S

6

1R12-830989-AB

SILL PLATE-V12 VANQ VEHICLE NAME

6

4R12-836204-AA

SILL PLATE VEHICLE NAME(PAIR)

7

1R12-80-10477

SILL PLATE VANQ S

7

1R12-80-10476

SILL PLATE VANQ V12

8

699108

SCREW No4 x 12 C/SNK RSD HD

9

697603

Screw, M6 x 25, Csk Socket Hd

10

1R12830226AEW

Sunvisor assy, trimmed, RH

10

1R12830225AEW

Sunvisor assy, trimmed, LH

10

4R12-830226-AAW

SUNVISOR ASSY RHS TRIMMED - MIRROR

10

4R12-830225-AAW

SUNVISOR ASSY LHS TRIMMED - MIRROR

11

1R12-835394-AB

SUN VISOR MOUNTING PIN INNER

12

1R12-833592-AC

REAR LAMP - FINISHER RH

12

1R12-832496-AC

SUNVISOR MNTG PIN

13

1R12-833593-AC

REAR LAMP FINISHER LH

14

1R12-831340-AF

SIDE STRAKE ASSY RH FENDER

14

1R12-784295-AB

FRONT AIRDAM EXTRUSION

14

1R12831392AE

Side strake rear, RH

15

5R13-13550-PIA2

DOUBLE SIDED TAPE 3M 5361

15

1R12-834648-AB

SIDE STRAKE ASSY FENDER RH SATIN CHROME

15

1R12-834649-AB

SIDE STRAKE ASSY FENDER LH SATIN CHROME

15

1R12-831392-AF

SIDE STRAKE-DOOR-RH

15

1R12-831393-AF

SIDE STRAKE-DOOR-LH

15

1R12-831341-AF

SIDE STRAKE ASSY- FENDER LH

15

1R12831393AE

Side strake rear, LH

16

1R12-835044-AA

REINF BAR - FRONT HEADER SUBSTRATE

17

697431

NUT M4 NYLOC

18

692054

WASHER M4 PLAIN MED MILD STEEL ZINC PLT

19

697517-PK

WASHER-M6 LGE OD BLK PACK OF 20

20

699969-PK

RIVET-R LOK PACK 10

21

1R12-632802-AB

DRAIN HOSE

22

1R12-634144-AC

LEAF SCREEN - PLENUM CUP RH

22

1R12-634145-AC

LEAF SCREEN - PLENUM CUP LH

23

1R12-633944-AB

DRAIN - CUP PLENUM

23

1R12-633945-AB

DRAIN CUP - PLENUM

23

699233-PK

TIE-STRAP HT RES-100

23

1R12-632220-AE

DRAIN TUBE-PLENUM OUTER

24

699508

PINE TREE CLIP

25

97-90423

AIRBAG WARNING LABEL ENGLISH

25

97-90425

AIRBAG WARNING LABEL

25

97-90434

AIRBAG WARNING LABEL FRENCH

25

97-90424

AIRBAG WARNING LABEL FRENCH

25

1R12-785178-AB

WATER DEFLECTOR RH

25

1R12-785177-AB

WATER DEFLECTOR LH

25

703265

Screw, M6 x 16, Hex Flange Head

25

700270

SCREW M6x10 FLG

25

699620

GROMMET (BLIND) SUPPLIER PART No 89736

25

1R12-632656-AB

COLLAR-HINGE SPACING

25

700226

WASHER PLAIN M6x17

25

1R12-634756-AA

CLIP - HEATSHIELD

25

703163

Nut, M6, Hex Flange Head, Locking
