No

Kod

Parça Adı

1

1R12-34-10228

CARBON CANNISTER

2

1R12-342549-AB

ENCLOSURE CARBON CANISTER

3

1R12-342550-AC

LID - ENCLOSURE CARBON CANISTER

4

1R12-342717-AB

GAITER - CARBON CANISTER

5

1R12-342787-AB

SPACER - CARBON CANISTER

6

700009

SEALANT STRIP CANISTER BOX/LID

7

697636

M5 x 20 FLG HD

8

695437

BOLT M6 x 35 HEX FLG GRD 8 8 ZINC PLATE

9

6R13-9C098-AB

BRACKET EVAP CANISTER

9

6R13346363AA

Quick connector, female

9

700008

EDGE CLIP - CANISTER BOX/LID

10

1R12-340696-AD

HOSE - PRIMARY TO SECONDARY CANISTER

10

6R13-340696-AA

PIPE - PRIMARY TO SECONDARY CANISTER

11

1R12-34-10666

VLV-EVAP CANNISTER

12

1R12-342957-AF

HOSE - CANISTER TO PURGE FILTER

18

1R12-342077-AA

CLIP - HOSE 20/8

14

1R12-34-10010

AIR FILTER

15

1R12-342956-AD

HOSE-FLVV TO CANNISTER

15

6R13-342956-AA

HOSE - FLVV TO CANISTER

15

1R12-34-10335

MTG BRACKET-CCV

19

34-85178

SENSOR-FTPT-REMOTE

20

1R12-343803-AB

ASSY CONNECTOR CARBON CANISTER

20

6R13-343803-AA

ASSY CONNECTOR CARBON CANISTER

21

703169

NUT - M6 HEX FLANGE CHROME FREE

22

1R12343923AA

Hose, close valve to filter pipe

23

1R12343313AC

Pipe, filter to valve connector

24

1R12-342705-AG

PIPE - CAN TO B/HEAD JUMP HOSE

25

699873

WASHER PLAIN 5.3x13

26

697163

WASHER M8 X 20.5 PLAIN FORM C

27

699844

SCREW M8 x 30 HEX

28

1R12-343584-AA

BUNG - CARBON CAN PIPES

29

699690

SEALING WASHER M5

30

697431

NUT M4 NYLOC

31

699762

SEALING WASHER

32

699845

WASHER M5x10x1 PLAIN

33

1R12344562AA

Clip, hose 17/8

34

1R12-340701-AH

PIPE - CONNECTOR TO B/HEAD

35

1R12343187AA

Hose, carbon canister connector

35

1R12-372754-AA

HARNESS - CARBON CANISTER
