No

Kod

Parça Adı

1

1R12-832814-AC

FLIP SEAL - IP TO SCREEN

2

1R12-69-10189

Vent, screen demist, RH

3

699646

Spring clip

3

697666

Adhesive tape, double sided

3

1R12835071AA

Foam seal, demist to dash

3

1R12-69-10190

SCRN DEMIST VENT LH

4

1R12-832292-AEW

SCUTTLE TRIM TRIMMED

4

1R12-833075-AA

SCUTTLE TRIM SUPPORT BRACKET - LOWER

38

700126

SCREW M6x20 HEX FLG

4

1R12-831235-AD

SCUTTLE TRIM ASSY UNTRIMMED

33

3R12-375518-AB

SWITCH SURROUND SATIN CHROME

33

1R12-831982-AD

SWITCH SURROUND - CENTRE CONSOLE

5

1R12-831362-ADW

IP ASSY RHD

5

1R12-831363-ADW

IP ASSY LHD

6

1R12-832336-ADW

PANEL INSTRUMENT BNCL TRIMMED RHD

6

1R12-832337-ADW

PANEL INSTRUMENT BNCL TRIMMED LHD

6

6R13-832244-AAW

PANEL UPPER CENTRE CONSOLE ASSY-TRIMMED

6

1R12-832336-ABW

PANEL INSTRUMENT BNCL TRIMMED RHD

6

1R12832337ABW

Panel, instrument cowl, trimmed

6

1R12832244AAW

Panel, upper centre, trimmed

40

700986-PK

Nut-M4 HEX FLG Pack of 20

7

1R12-833888-AC

INSTRUMENT COWL ASY

7

1R12-833889-AC

INSTRUMENT COWL ASSY

8

5R13-C04562-BAW

DRIVER END CAP SWITCH ASSY RH RHD

8

5R13-C04563-AAW

PASSENGER END CAP ASSY RH LHD

8

1R12-834242-AAW

PASSENGER END CAP ASSY RH LHD

8

1R12-834240-AAW

DRIVER END CAP SWITCH ASSY RH RHD

8

3R12834242AAW

Passenger end cap switch assy, RH LHD

8

3R12834240AAW

Driver end cap switch assy, RH RHD

9

5R13-C04562-AAW

DRIVER END CAP SWITCH ASSY LH LHD

9

5R13-C04563-BAW

PASSENGER END CAP ASSY LH RHD

49

697495

SCREW No8 x 13 FLANGED AB S.T

43

703265

Screw, M6 x 16, Hex Flange Head

9

697286

Washer M6 Large OD

9

697141-PK

NUT-M8 NYLOC(PACK 10

9

1R12-834243-AAW

PASS END CAP ASSY LH RHD

9

1R12-834241-AAW

DRIVER END CAP SWITCH ASSY LH LHD

9

3R12834243AAW

Passenger end cap switch assy, LH RHD

9

3R12834241AAW

Driver end cap switch assy, LH LHD

10

1R12835605AA

Vent, side demist

11

1R12-834259-AA

AIR VENT LH

12

1R12-834260-AA

AIR VENT RH

12

700110

SCREW No6x3/8in POZI

13

1R12-37-10156

SWITCH-KEYBOARD

14

1R12-37-10157

SWITCH-FUEL/BOOT REL

15

5R13-F045H84-AAW

TRIP COMPUTER BEZEL (TO COLOUR REQUIRED)

15

1R12-37-10158

BEZEL-TRIP COMPUTER

16

1R12-831366-AL

LOWER STRUCTURE IP ASSY RHD

16

1R12-831367-AL

LOWER STRUCTURE IP ASSY LHD

17

1R12-832813-AE

ASSY - GLOVE BOX INNER RHD

17

1R12-832812-AE

ASSY - GLOVE BOX INNER LHD

18

1R12-831898-AA

Damper, glove box lid

19

1R12-831900-AA

PULLY (CORD ASSY)

20

1R12-834547-AA

STRING (CORD) ASSY

21

1R12-830898-AD

GLOVE BOX INNER RHD

21

1R12-830899-AD

GLOVE BOX INNER LHD

22

1R12-834534-AA

TRAY - MULTI TOOL KIT (FOR TYRE PRESSURE GAUGE)

23

1R12832268AEW

Glove box lid assy LH, trimmed

23

1R12-832269-AEW

KNEE BOLSTER / GLOVE BOX LID ASSY - TRIMMED

24

1R12-69-10350

HINGE-GLOVE BOX

25

5R13-061A12-AAW

GLOVEBOX LATCH HANDLE - TRIMMED

25

697514

WASHER OVAL 1 x 1/2 x 7/32

25

1R12-835453-AA

Spacer, glove box latch

25

1R12-832245-AB

GLOVE BOX LATCH

26

699818-PK

SCREW M6x20 SKT (10)

26

1R12832266AHW

Knee bolster assy, driver, trimmed

26

1R12-832267-AHW

KNEE BOLSTER DRIVER ASSY - TRIMMED

26

1R12-69-10046

LOCK BARREL-GLOVEBOX

27

5R13-C06024-BAW

KNEE BOLSTER / GLOVE BOX LID ASSY RHD - TRIMMED

27

5R13-C06024-AAW

KNEE BOLSTER /GLOVE BOX LID ASSY LHD - TRIMMED

27

1R12-831252-AG

KNEE BOLSTER DRIVER ASSY - UNTRIMMED

27

1R12-831253-AG

KNEE BOLSTER DRIVER ASSY - UNTRIMMED

28

1R12-890070-AF

ADAPTOR - VENT CENTRE FACE

29

697591

SCREW No8 x 9.5 FLANGED AB S.T.

29

311298

CENTRE AIR VENT

55

700275

SCREW 4.2x13 WSHR HD AB

30

697565

Spire Nut

30

5R13-C04350-ABW

TRIMMED PANEL - CENTRE CONSOLE ASSY

30

6R13-C04350-AAW

TRIMMED PANEL - CENTRE CONSOLE ASSY

30

1R12-834468-ADW

PANEL CENTRE CONSOLE ASSY - PAINTED

30

4R12-834468-AAW

PANEL CENTRE CONSOLE ASSY

30

1R12835280AAW

Panel, centre console, painted, body colour

30

1R12835281AAW

Panel, centre console, painted, any colour

31

6R13-834856-AAW

ASSY CENTRE CONSOLE SIDE CLOSER RH

31

1R12-834856-AAW

ASSY CENTRE CONSOLE SIDE CLOSER RH RHD

31

1R12-834858-AAW

ASSY CENTRE CONSOLE SIDE CLOSER RH LHD

32

6R13-834857-AAW

ASST CENTRE CONSOLE SIDE CLOSER LH

32

1R12-834857-AAW

ASST CENTRE CONSOLE SIDE CLOSER LH RHD

32

1R12-834859-AAW

ASSY CENTRE CONSOLE SIDE CLOSER LH LHD

33

5R13-19A200-AA

ASSY - SURROUND - CARD TRAY

34

80-90018

CONSOLE BADGE- ASTON MARTIN

35

3R12-375517-AB

DRW FRT SAT CHROME

35

1R12-834359-AC

CARDHOLDER DRAWER FRONT

35

5R13-19A201-AA

DRAWER FRONT COIN TRAY

35

4R12-376205-AA

DRAWER FRONT COIN TRAY

35

1R12-834365-AA

COIN TRAY

36

1R12-69-10204

LATCH PLATE-PASS LH

37

700612

Screw, M4 x 16 pan hd, pozi

37

700272

WASHER M4x9x0.8

37

1R12-69-10205

LATCH PLATE-PASS RH

37

1R128310212

Kit, glovebox

50

702295

Nut, M5, Hex Flange Head

42

703202

Screw,  M8  x 12, Flange Hd

44

700253

PATCHLOCK M8x20 HEX

45

1R12-834816-AAW

Door, fusebox cover, trimmed

45

3R12-834816-AAW

DOOR FUSEBOX COVER TRIMMED ASSY

46

41-84347

WASHER M8 x 25mm OD HARDENED

47

700130

NUT M8 HEX P/T PLAS8

48

699798

SCREW M6x16 SKT BTN FLG BLK

51

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

52

700613

Screw, flg, M6, x 12

53

699614

WASHER 22 X 6.8 X 2 STAINLESS

54

697177

Nut, M6, Flanged

55

97-84799

LABEL-CHILD SAFETY AIRBAG WARNING RHD

55

97-84800

LABEL-CHILD SAFETY AIR BAG WARNING LHD

56

1R12834056AA

Bracket, side panel

57

37-85271

SEAL STRIP-SELF ADH.

57

700168

Screw, M6 x 12
