No

Kod

Parça Adı

1

4G4E6D080AA

Front cover

1

03-85063

FRONT COVER

2

03-85064

Gasket, Engine Front Cover

3

03-85065

Gasket, Front Cover, Centre

4

03-85066

Gasket, Front Cover, RH

5

W701525S437

Bolt and washer, M8 X 47.5, hex flg

6

W701232S437

Bolt and washer, M8 X 32, hex flg

7

03-85067

Oil Seal, Crankshaft, Front

8

4G43-02-10012

CRANKSHAFT SPROCKET- TWIN- 21T

9

1R12-07-10720

SENSOR RING-IGNITION

10

1R12-07-10378

SPROCKET-CAMSHAFT INLET RH

10

0785070

Sprocket, camshaft, intake, RH

11

1R12-07-10379

SPROCKET-CAMSHAFT EXH RH

11

0785071

Sprocket, camshaft, exhaust, RH

12

1R12-07-10376

SPROCKET-CAMSHAFT INLET LH

12

0785072

Sprocket, camshaft, intake, LH

13

1R12-07-10377

SPROCKET-CAMSHAFT EXH LH

13

0785073

Sprocket, camshaft, exhaust, LH

14

07-85074

CAM SPROCKET WASHER

15

697739

BOLT-M12 x 52.5

16

1R12-03-10483

Chain, Timing

17

1R12-03-10069

Guide Assembly, Timing Chain, RH

18

697749

BOLT-M8 x 32 FLG

19

1R12-03-10070

Guide Assembly, Timing Chain, LH

23

697741

BOLT-M8 x 49.3 FLG

21

4G43-03-10013

Arm Assembly, Timing Chain

22

1R12-03-10071

Tensioner, Timing Chain

24

1R12-39-10475

Sensor, Crankshaft, Front

25

702542

BOLT M6 x 20 HF PIL 8

25

4G43-39-10014

Sensor Assy, Crankshaft, Rear

25

07-85755

Sensor Assy, Crankshaft Timing
