No

Kod

Parça Adı

1

1R12-29-10124

PEDAL HOUSING

2

703201

SCREW M8 x 30 HEX FLANGE CHROME FREE

3

1R12-29-10125

GASKET-PEDAL HOUSING

4

1R12291404AF

Adaptor, pedal box

5

1R12-293607-AC

GASKET ADAPTOR PEDAL BOX

6

703188

SCREW M8 x1.25 x 20 FLANGE HEX HEAD CHROME FREE

7

29-81255

PIVOT PIN- BRAKE PEDAL

8

697291

NUT M10 NYLOC

9

697258

WASHER M10 PLAIN FORM A

10

4R12-296298-AA

BRAKE PEDAL SUB/ASSY RHD

10

4R12-296299-AA

BRAKE PEDAL SUB/ASSY LHD

10

1R12-292846-AC

BRAKE PEDAL RHD MODIFIED

10

1R12-292847-AC

BRAKE PEDAL LHD MODIFIED

11

700447

CAPSCREW- M5x36 CSK HD FOOTREST PAD TO BRKT

11

700448

Screw, M5 x 30, csk Pedal pad

11

1R12-382811-AE

PAD - BRAKE PEDAL

11

1R12-384328-AB

PAD - BRAKE PEDAL LHD

21

703165

NUT M5 HEX FLG PLAS CHROME FREE

12

29-81257

SPRING

13

29-81271

BUSH-PEDAL PIVOT

14

29-84879

Pin, Joint

15

703273

WASHER WAVE SPRING M8

16

6G33-27328-AA

Clip, Safety, Nom Shaft, 5/16

17

37-85782

Switch-Stop Lamp

18

702295

Nut, M5, Hex Flange Head

19

90-84092

GASKET

20

1R12-382240-AC

ASSY ACCEL PEDAL RHD

21

1R12-382239-AD

ASSY ACCEL PEDAL LHD

21

1R123710339

Sensor, accelerator pedal position

21

1R12-382716-AB

PAD ACCELERATOR PEDAL

21

700451

PEDAL PAD SCREW M5 X 20 SCREW

22

703265

Screw, M6 x 16, Hex Flange Head

23

1R12-384737-AB

SPACER - BRAKE PEDAL RHD

23

1R12-384327-AB

SPACER - BRAKE PEDAL LHD
