No

Kod

Parça Adı

1

4G43-16-10879S

Panel assy, floor, RH

2

FD33-11141-AC

PANEL FLOOR LH

3

8G43-67342-AA

SEAT FINISHER REAR SEAT HEEL BOARD LOWER RH

4

4G43-20-10876

FRONT SUBFRAME UPRIGHT ASSY RH-DB9

5

4G43-20-10877

FRONT SUBFRAME UPRIGHT ASSY-LH DB9

6

8G43-434K10-AA

NUTPLATE FRONT END MOUNTING OUTER RH M12

7

8G43-434K11-AA

NUTPLATE FRONT END MOUNTING OUTER LH M12

8

8G43-390725-AA

NUT PLATE FRONT END MOUNTING INR M12

9

GOAG33-F001K28-AA

Bracket, tunnel upper inner

10

DG43-10120-AA

Member, Floor, Side Front

11

DG43-L10116-AD

Member, Floor Side, RH

12

ED33-L10117-AA

Member, Floor Side, LH

13

DG43-L24312-AC

Pillar, Centre Body, RH

14

DG43-L24313-AC

Pillar, Centre Body, LH

15

DG43-L24314-AA

Pillar, Centre Body, Outer Rear, RH

16

DG43-L24315-AA

Pillar, Centre Body, Outer Rear, LH

17

ED33-101D06-AA

Extrusion Member, Rear Floor Side Lower, RH

18

ED33-101D07-AA

Extrusion Member, Rear Floor Side Lower, LH

19

ED33-L243A60-AE

REINF CTR BDY UPR

20

ED33-L243A61-AE

REINF CTR BDY UPR

21

6G33-68676-AC

Rivet Structural 6.5 x 14, Blind

22

6G33-68885-AB

SELF PIERCING RIVET 5.0 x 6.0mm

23

6G33-33800-AA

Rivnut, 7/16UNF hex flange

24

6G33-37949-AA

DIA 4.8 X 13.9 BLIND RIVET
